TESTEX Rotary Crockmeter (TF412)
- It’s 16mm dia. rubbing head.
- It’s 1134g vertical pressure.
- It’s Rotation: 1.125 turns.
- It’s Standards AATCC 116, ISO 105×16.
TESTEX Rotary Crockmeter (TF412) is used to test the color density through the rubbing of materials such as fabric, carpeting, yarn and leather in textiles. You can use the this Crockmeter for the color test and the TESTEX Rotary Crockmeter price is also competitive. Both wet and dry sampling material can be tested through Crockmeter.
FEATURES OF TESTEX ROTARY CROCKMETER (TF412)
- It’s 16mm dia. rubbing head.
- It’s 1134g vertical pressure.
- It’s Rotation: 1.125 turns.
- It’s Standards AATCC 116, ISO 105×16.
SPECIFICATIONS OF TESTEX ROTARY CROCKMETER (TF412)
| Name | Details |
|---|---|
| Model | TF412 |
| Brand | TESTEX |
| Origin | China |
| Rubbing Head | Dia 16mm |
| Vertical Pressure | 1134g |
| Rotation | 1.125 turns |
| Dimensions (Length x Width x Height) | (250 x 350 x 450)mm |
| Power | 220V |
| Weight | 25 pound / 11.3 kg |
ACCESSORIES OF TESTEX ROTARY CROCKMETER (TF412)
| Name | Details |
|---|---|
| Rubbing Cloth | 1 Box (1000 Pieces) |
| Sand Paper | 2 Pieces |
| Ring | 2 Pieces |
STANDARD OF TESTEX ROTARY CROCKMETER (TF412)
| Name |
|---|
| AATCC 116 |
| ISO 105×16 |
TABLE 5 DYES AND TYPES OF STRUCTURE OF BLUE WOOL STANDARD SAMPLE
| Standards | Name of Dyes | Dye Index Number | Chemical Class |
|---|---|---|---|
| Grade 1 | Acid Brilliant Blue FFR | C.I. Acid Blue 104 | Triphenylmethane |
| Grade 2 | Acid Brilliant Blue FFB | C.I. Acid Blue 109 | Triphenylmethane |
| Grade 3 | Acid Pure Blue 6B | C.I. Acid Blue 83 | Triphenylmethane |
| Grade 4 | Acid Pure Blue EG | C.I. Acid Blue 21 | Azine |
| Grade 5 | Acid Blue RX | C.I. Acid Blue 47 | Anthraquinone |
| Grade 6 | Acid Light Blue 4GL | C.I. Acid Blue 23 | Anthraquinone |
| Grade 7 | Soluble Reduced Blue 04B | C.I. Solubilized Vat Blue 5 | Anthraquinone |
| Grade 8 | Soluble Reduced Blue AGG | C.I. Solubilized Vat Blue 8 | Anthraquinone |
VIDEO REVIEW OF TESTEX ROTARY CROCKMETER (TF412)
